13th Gen Intel® Core™ i7-1370PE
13th Gen Intel® Core™ i5-1340PE
13th Gen Intel® Core™ i3-1320PE
Specification
System
CPU
Memory
Onboard LPDDR5 16 GB(i7-1370PE/i5-1340PE), Onboard LPDDR5 8 GB (i3-1320PE)
Storage
1 x 2.5” Internal HDD Bay
1 x M-Key 2280, NVMe SSD
1 x M-Key 2280, NVMe SSD
Real Time Clock
Yes
Security
TPM 2.0
Thermal Design
Fanless design
Operating System
Ubuntu 22.04 LTS, Yocto 4.0
Windows 10 Enterprise 2021 LTSC
Windows 10 Enterprise 2021 LTSC
Power Requirement
Input Voltage
12 ~ 36 VDC
Power Consumption
90 W (typical)
Power Connector
1 x 5.5 mm x 2.5 mm DC input
Environmental and Mechanical
Dimension
150 x 124 x 67 mm (5.91” x 4.87” x 2.64”)
Weight
1.1 kg
Operating Temperature
0 ~ 50 °C (32 ~ 122 °F)
Storage Temperature
-40 ~ 80 °C (-40 ~ 176 °F)
Operating Humidity
5% ~ 95% relative humidity (RH), non-condensing
Certification
Regulations
CE, FCC, RoHs
Interface
Serial Port
1 x RS232/422/485 DB9
CAN Bus
1 x RJ45 Intel® I219 GbE LAN, 1 x RJ45 Intel® I226IT 2.5GbE LAN
Ethernet
3 x USB 3.2 Gen2 (Type A)
1 x USB 2.0 (Type A)
1 x USB 4.0 (Type C)
1 x USB 2.0 (Type A)
1 x USB 4.0 (Type C)
Display
1 x HDMI, 1 x DP, 1 x DP 1.4a (via USB Type-C)
Expansion Slot
1 x M.2 B-Key 3042/3052, 1 x M.2 E-Key 2230
SIM Slot
1 x Nano SIM Card Socket
Antenna
5 x External Antenna holes
