車載數位錄影主機
EMV400 FHD-N
4路1080p Full HD 車載錄影主機
• Full HD mobile DVR (AHD/TVI/CVI/CVBS)
• Up to 1080p full-HD resolution for recording
• Supports H.264/H.265 video compression
• Supports UTC function
• Supports 2.5" SSD x 1 (Max. 2TB)
• Provides one 1Gb Ethernet port
• 3-axis G-sensor embedded
• Supports multiple serial interfaces
• Internal temperature control (built-in 2 heaters)
• IR remote control function
• M12 Aviation connectors adopted
• Supports mobile applications (MobileFocus)
• Multiple network monitoring: Web viewer, XFleet fleet management server system
• Certificates: CE, FCC, EN50155
• SAE-J1455 (shock & vibration only)
• Up to 1080p full-HD resolution for recording
• Supports H.264/H.265 video compression
• Supports UTC function
• Supports 2.5" SSD x 1 (Max. 2TB)
• Provides one 1Gb Ethernet port
• 3-axis G-sensor embedded
• Supports multiple serial interfaces
• Internal temperature control (built-in 2 heaters)
• IR remote control function
• M12 Aviation connectors adopted
• Supports mobile applications (MobileFocus)
• Multiple network monitoring: Web viewer, XFleet fleet management server system
• Certificates: CE, FCC, EN50155
• SAE-J1455 (shock & vibration only)
規格
Video
頻道數量
4 CH
視訊壓縮
H.264 / H.265
主螢幕
VGA x 1
通話監聽
BNC x 1 / RCA x 1
警報輸入
4 / 2
視頻損失檢測
Yes
事件警報
Yes
Audio
音源輸入
4
音源輸出
1 (RCA)
錄影
錄影檔案解析度
1080p / 720p / 960H / D1 / 2CIF / CIF / QCIF
錄影模式
Event, Normal + Event, Schedule
NTSC 錄影幀率
30fps
PAL 錄音幀率
25fps
預警錄影
Yes
回放
回放模式
Duplex
回放搜尋
Event, Normal + Event, Schedule
視頻
警報輸出
4 / 2
Network
Ethernet 以太網路
RJ-45 port x 1 (10/100/1000M)
WiFi
Yes (Optional)
4G / 5G
3G / 4G
GPS
Yes (Optional)
儲存裝置
硬碟
2.5" SSD x 1 (Max. 2TB)
SD卡
SD/SDHC Card (Max. 32 GB) – for alarm event backup recording only
General
Interfaces
RJ-45 x 1, RS-232 x 3, RS-485 x 1, USB x 3
GSensor
3-Axis G-Sensor embedded
系統控制
IR Remote Control, Mouse, Web UI
PTZ 控制
Yes
電源
9-36 VDC
電力消耗
20W / 60W (Heater On)
操作溫度
-40°C~55°C / -40°F~131°F
尺寸 (寬 x 深 x 高)
229.6 x 218 x 63.4mm / 9.04" x 8.58" x 2.5" (With Anti-Vibration Bracket)
Weight
With Anti-Vibration Bracket: 2.6kg / 5.73lb
證書
CE, FCC, EN50155, SAE-J1455 (shock & vibration only)
遠端客戶端系統最低要求
作業系統
Windows XP (32-bit) / Win7 (32 and 64-bit)
CPU
Intel Core I3-2100
RAM
2GB
區域網速
10 / 100 / 1000 Mbps (RJ45)
Web 瀏覽器
IE11 and later, Firefox 50 and earlier, Chrome 44 and earlier, EF browser
遠端客戶系統最低要求
Graphic
Intel HD 2000
